Injap Bola Kekuatan Tinggi PPH DN25 hingga DN150

Jenis bayaran:L/C,T/T,D/P,D/A,Paypal

Incoterm:FOB,CFR,CIF

Pesanan minimum:1

Pengangkutan:Ocean,Land,Air

$0.1-1 /

Atribut Produk
Membekalkan Keupayaan & Maklumat Tambaha...
Pembungkusan & Penghantaran

Atribut Produk

Jenama: HY atau OEM

Tempoh Jaminan: 3 tahun

Jenis: Injap bola

Penyesuaian Sokongan: OEM

Tempat Asal: China

Permohonan: Umum

Suhu Sederhana: Suhu normal

Kuasa: Hidraulik

Medium Aliran: Air, Minyak, Asid

Struktur: Bola

Membekalkan Keupayaan & Maklumat Tambaha...

Pengangkutan: Ocean,Land,Air

Jenis bayaran: L/C,T/T,D/P,D/A,Paypal

Incoterm: FOB,CFR,CIF

Pembungkusan & Penghantaran

Injap Bola Kekuatan Tinggi PPH premium kami ialah injap bola pph tugas berat yang direka bentuk untuk ketahanan industri, tersedia dalam injap bebola praktikal 2 1 2 dan saiz serasi injap bola 6 pvc untuk keperluan paip serba boleh. Dihasilkan daripada PPH berkekuatan tinggi, ia memberikan rintangan kimia/kakisan yang unggul, pengedap kalis bocor yang ketat dan penggerak yang lancar. Dibina untuk prestasi jangka panjang, ia sesuai untuk sistem cecair industri tekanan sederhana rendah, pemprosesan kimia dan aplikasi rawatan air.

HuiYa PVC fittings series
DIN	ANSI	JIS
PVC PN10	PVC SCH40
PVC PN16	PVC SCH80

Key Word:	PVC-U 90 degree elbow Pipe joints fittings
Connect Type:	Cement-Glue-Socket
Brand:	HUIYA or OEM
Material:	PVC(PVC-U)
Specifications:	Size(dimensions):	DN15-20-25-32-40-50-65-80-100-125-150-200-250-300-350-400
		20-25-32-40-50-63-75-90-110-125-140-160-200-225-280-315-355-400mm
	Color:	Grey
	Standard:	ISO , ISO4422, , DIN8063,GB/T 4219.2
	Working pressure:	PN16(1.6Mpa)
	Working temperature:	-15 to 55 Degree Celsius
	Production Process:	Mold Injected
	Packing:	Cartons
Advantage:	1.100% virgin PVC material
	2.Environmentally friendly material, 100% no lead, zinc and other metals, water quality unaffected,harmless to the body
	3.Strictly produced according to ISO standard
	4.Long lifetime
	5.The pressure resistance reaches 1.6 MPa, Good chemicals and drugs resistance
Application:	Connected with PVC-U pipes for portable water supply，also can be used for corrosive medium transportation in chemical industry and other fields
HS Code:	391740
Certificate:	SGS
Brief Introduction:	HuiYa Plastic Co., Ltd is a professional supplier of UPVC-CPVC-PE-PPR Pipes, pipe fittings, valves,Upvc Pipe Fittings And Valves,Pph Pipe Fittings And Valves. Plastic piping systems such as pipes, fittings and valves is widely used in water supply, chemical industry, water treatment, environmental protection, pharmaceutical area etc.
	We insist in the principal of Quality First, Clients First". Your satisfaction is our eternal pursuit. With high-class raw material, strict quality control in both the workshop and laboratory with various professional testing equipment, HuiYa Plastic ensures that every single product meets the corresponding inspection standard.

Sebagai pengeluar profesional terkemuka, kami pakar dalam menyediakan injap bola kekuatan tinggi PPH Borong yang direka bentuk untuk persekitaran perindustrian yang paling mencabar. Barisan produk kami, yang menampilkan rangkaian Injap Bola PPH DN15-DN100 serba boleh, direka untuk memberikan kekuatan mekanikal yang luar biasa dan kebolehpercayaan jangka panjang.

high-strength-ball-valve-automated-platform.j

PPH DIN Strong Flanged Ball Valve For Automation Dimensions Table (mm)
DN	D1	D	L	h	n	φ	(Mpa)working pressure			J	M
DN	D1	HG/DIN	HG/DIN	h	HG/DIN	HG/DIN	FRPP/PPH	UPVC/CPVC	PVDF	J	M
25	115	85	172	16	4	14	1.0	1.6	1.6	70	11
32	135	100	175	16	4	18	1.0	1.6	1.6	70	11
40	145	110	182	18	4	18	1.0	1.6	1.6	70	14
50	160	125	189	18	4	18	1.0	1.6	1.6	70	14
65	180	145	218	20	4	18	1.0	1.0	1.0	102	17
80	195	160	244	20	8	18	1.0	1.0	1.0	102	17/22
100	215	180	297	23	8	18	1.0	1.0	1.0	102	17/22
125	245	210	390	24	8	18	0.8	1.0	1.0	125	22/27*
150	280	240	390	24	8	22	0.8	1.0	1.0	125	22/27*

PPH ANSI Strong Flanged Ball Valve For Automation Dimensions Table (mm)
DN	D1	D	L	h	n	φ	(Mpa)working pressure			J	M
DN	D1	ANSI	ANSI	h	ANSI	ANSI	FRPP/PPH	UPVC/CPVC	PVDF	J	M
25	115	79	172	16	4	16	1.0	1.6	1.6	70	11
32	135	89	175	16	4	16	1.0	1.6	1.6	70	11
40	145	98	182	18	4	16	1.0	1.6	1.6	70	14
50	160	121	189	18	4	19	1.0	1.6	1.6	70	14
65	180	140	218	20	4	19	1.0	1.0	1.0	102	17
80	195	152	244	20	4*	19	1.0	1.0	1.0	102	17/22
100	215	190	297	23	8	19	1.0	1.0	1.0	102	17/22
125	245	216	390	24	8	22	0.8	1.0	1.0	125	22/27*
150	280	241	390	24	8	22	0.8	1.0	1.0	125	22/27*
